Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    4.1
  • Stroke (in):
    3.35
  • Displacement (cc):
    722
  • Fuel Type:
    Gas
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Kill Switch / Tether Cord:
    Not Available
  • Engine Block Heater:
    Not Available
  • Snorkel Air Intake:
    Standard
  • Starter:
    Electric
  • Compression ratio:
    9.9:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Transmission Brand:
    Quadmatic™
  • Primary Drive (Front Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    3
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    No
  • Limited Slip Differential:
    Standard
  • Differential Lock:
    Standard
  • Limited Slip Differential Location:
    Front
  • Differential Lock Location:
    Front
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    47.8
  • Height (in):
    50.6
  • Wheelbase (in):
    50.6
  • Ground Clearance (in):
    10.2
  • Fuel Capacity (gal):
    4.6
  • Towing Capacity (lbs):
    1322
  • Storage Capacity (gal):
    0.6
  • Wet Weight (lbs):
    725
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    6.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Travel (in):
    7.7
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Front Stabilizer Bar:
    No
  • Rear Stabilizer Bar:
    Yes
  • Steering Damper:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Front Tire (Full Spec):
    Carlisle AT 25 X 8-12
  • Rear Tire (Full Spec):
    Carlisle AT 25 X 10-12
  • Spare Tire:
    Not Available
  • Tube / Tubeless:
    Tubeless
  • Chromed:
    No
  • Tire Chains:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    7.9
  • Rear Brake Type:
    Sealed Oil Bath Multi-Disc
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Engine Braking Brand Name:
    Engine Braking System
• TOWING & HAULING

  add remove
  • Front Hitch:
    Not Available
  • Rear Hitch:
    Standard
  • Trailer:
    Not Available
  • Winch:
    Optional
  • Roller Fairlead:
    Optional
  • Rear Hitch Type:
    Receiver
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    36.2
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Grab Rail or Strap:
    Not Available
