Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.33
  • Stroke (in):
    2.96
  • Displacement (cc):
    421
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Valves Per Cylinder:
    2
  • Speed Governor:
    No
  • Fuel Injector Size (mm):
    34
  • Compression Ratio:
    10.0:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Brand:
    UltraMatic™
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    46.5
  • Height (in):
    45.7
  • Wheelbase (in):
    48.8
  • Ground Clearance (in):
    9.6
  • Fuel Capacity (gal):
    3.7
  • Engine Displacement to Weight (cc):
    0.67
  • Towing Capacity (lbs):
    1322
  • Wet Weight (lbs):
    637
  • Payload Capacity (lbs):
    264
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    6.7
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Independent Double Wishbone
  • Rear Travel (in):
    7.4
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Tube / Tubeless:
    Tubeless
  • Front Tire Diameter (in):
    25
  • Rear Tire Diameter (in):
    25
  • Front Tire (Full Spec):
    AT25 x 8 - 12
  • Rear Tire (Full Spec):
    AT25 x 10 - 12
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Sealed Oil Bath Multi-Disc
