Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    4.02
  • Stroke (in):
    4.09
  • Displacement (cc):
    1700
  • Compression Ratio:
    9.5:1
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Fuel Requirements:
    Regular
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    108
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    100.8
  • Width (in):
    39.2
  • Height (in):
    61
  • Wheelbase (in):
    65.6
  • Ground Clearance (in):
    5.3
  • Wet Weight (lbs):
    895
  • Fuel Capacity (gal):
    5.3
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.8
  • Front Travel (in):
    5.5
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.1
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
  • Steering Damper:
    No
  • Air Adjustable:
    Yes
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    130/90 R16
  • Rear Tire (Full Spec):
    170/70 R16
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.8
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    11.8
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Height (in):
    28.7
  • Number Of Seats:
    2
