Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valve Configuration:
    SOHC
  • Bore (in):
    1.79
  • Stroke (in):
    2.17
  • Displacement (cc):
    90
  • Fuel Type:
    Gas
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Number Of Carburetors:
    1
  • Carburetor Size (mm):
    16
  • Carburetion Type:
    Carburetor
  • Kill Switch / Tether Cord:
    Standard
  • Engine Block Heater:
    Not Available
  • Snorkel Air Intake:
    Not Available
  • Speed Governor:
    Yes
  • Starter:
    Electric / Pull
  • Compression ratio:
    9.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Overdrive:
    No
  • Hi / Low Range:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Primary Drive (Engine / Transmission):
    Belt
• DRIVE LINE

  add remove
  • Driveline Type:
    4X2
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    Yes
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    34.4
  • Height (in):
    36
  • Wheelbase (in):
    39.6
  • Ground Clearance (in):
    5.9
  • Fuel Capacity (gal):
    1.6
  • Wet Weight (lbs):
    280
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent A-Arm
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Front Stabilizer Bar:
    No
  • Rear Stabilizer Bar:
    No
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Front Tire (Full Spec):
    Dunlop® AT 19 X 7-8
  • Rear Tire (Full Spec):
    Dunlop® AT 19 X 7-8
  • Spare Tire:
    Not Available
  • Tube / Tubeless:
    Tubeless
  • Chromed:
    No
  • Tire Chains:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Drum
  • Rear Brake Type:
    Drum
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
• TOWING & HAULING

  add remove
  • Front Hitch:
    Not Available
  • Rear Hitch:
    Not Available
  • Trailer:
    Not Available
  • Winch:
    Not Available
  • Roller Fairlead:
    Not Available
  • Tow Hook:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    25.6
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Grab Rail or Strap:
    Not Available
