Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.31
  • Stroke (in):
    2.76
  • Displacement (cc):
    776
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    12.8:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Primary Drive (Engine / Transmission):
    Gear
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    92.3
  • Width (in):
    38.4
  • Height (in):
    51.6
  • Wheelbase (in):
    61.8
  • Ground Clearance (in):
    8.7
  • Fuel Capacity (gal):
    5.3
  • Wet Weight (lbs):
    507
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    43
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Travel (in):
    8.7
  • Rear Travel (in):
    8.7
  • Front Suspension Brand Name:
    Showa®
  • Steering Damper:
    No
  • Air Adjustable:
    No
  • Rear Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    Dunlop® TRAILMAX MIXTOUR 90/90 R21 M/C 54H
  • Rear Tire (Full Spec):
    Dunlop® TRAILMAX MIXTOUR 150/70 R17 M/C 69H
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Diameter (in):
    10.2
  • Brake Brand Name:
    Nissin
