Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.03
  • Stroke (in):
    2.11
  • Displacement (cc):
    249
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    13.8:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Overdrive:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    86
  • Width (in):
    32.9
  • Height (in):
    49.4
  • Wheelbase (in):
    58.5
  • Ground Clearance (in):
    13
  • Fuel Capacity (gal):
    1.7
  • Wet Weight (lbs):
    233
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Adjustable Fork Pre-Load:
    Yes
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    Dunlop® Geomax MX33 80/100 R21 M/C 51M
  • Rear Tire (Full Spec):
    Dunlop® Geomax MX33 100/90 R19 M/C 57M
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Front Brake Diameter (in):
    10.6
