Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    2-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    Reed Valve
  • Bore (in):
    2.13
  • Stroke (in):
    2.15
  • Displacement (cc):
    125
  • Carburetion Brand:
    Keihin
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Number Of Carburetors:
    1
  • Carburetion Type:
    Carburetor
  • Compression Ratio (Secondary):
    10.2:1
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression ratio:
    7.8
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Gear Ratio (1):
    2.39
  • Gear Ratio (2):
    1.93
  • Gear Ratio (3):
    1.59
  • Gear Ratio (4):
    1.35
  • Gear Ratio (5):
    1.2
  • Gear Ratio (6):
    1.1
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    84.8
  • Width (in):
    32.5
  • Height (in):
    50.8
  • Wheelbase (in):
    57.3
  • Ground Clearance (in):
    14
  • Fuel Capacity (gal):
    1.8
  • Engine Displacement to Weight (cc):
    0.59
  • Wet Weight (lbs):
    212
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    11.8
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    12.4
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubed
  • Tires:
    Standard
  • Tire Brand:
    Dunlop®
  • Front Tire (Full Spec):
    Dunlop® Geomax MX33F 80/100 - 21
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.4
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    38.2
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Not Available
